Read File#

Screenshot showing a file reading interface.

When activated, the read file task reads a given file and outputs its content. The file path can be provided either by the input port or in the task settings.

Screenshot showing a file selection dialog with the filename "image26" displayed.

Inputs#

Name Description
path String File path
encoding String File content encoding
attempts Integer Number of attempts to perform this operation. Default is 1 attempt
sleepBetweenAttempts Integer Interval of time between the attempts. Default is 1000ms
Activate any Activate the task

Outputs#

Name Data Type Description
content Buffer | String Triggered when the task is executed. To output the file content
Success Boolean Triggered when the task is executed with success
Error Error Triggered when the task failed for some reason

Settings#

On the General tab, you have the usual settings and the following settings:

Name Data Type Values Default Description
File path String File path
Encoding Enum utf8
ucs2
utf16le
latin1
binary
base64
ascii
hex		 utf8 File content encoding
Content Type Enum Buffer
String		 String Type of the content to be emitted
Number of attempts Integer 1 Number of attempts to perform this operation.
Sleep Between Attempts Integer 1000 Interval of time between the attempts.

For the File path you can use tokens as represented below:

Available tokens:
  ${path} - Watched path
  ${archive} - Archive path
  ${temp} - Temporary directory of the user
  ${id} - DriverId ("\" chars replaced with "_")

Examples:
  ${path}\subdir\newFile.txt
  ${temp}\files\${id}\Recipe\File.csv
  c:\source\Result\OK.bin

Screenshot showing settings options.

Behavior#

In this task you choose a driver when dropping it into the workflow (if you have more than one driver associated with the controller).

Upon activation, will send a ReadFile command to the driver where it will try to read the contents of the file in the path location. If it fails, will retry attempts times, waiting sleepBetweenAttempts milliseconds each time.

When the operation is executed with success, both Success and content outputs emit their respective values. In case of the task , for some reason, is not able perform the operation, an Error is emitted.

Remarks#

There is no particular remark to be made.
