Write File#
This task write data to a file in OPC UA server using the File Transfer feature. To be used with OPC UA driver in Client mode.
Inputs#
| Name | Data Type | Description |
|---|---|---|
| nodeId | String | The node id where the file will be written |
| rawData | Buffer | The raw data to be written in the file |
| Activate | any | Activate the task |
Outputs#
| Name | Data Type | Description |
|---|---|---|
| Success | Boolean | If there was no problem emits a true |
| Error | Error | Error that occurred during the processing of this task |
Settings#
This task doesn't have any settings
Behavior#
Activate will trigger a message to the driver. The contents of the message are the values received in the inputs.
Remarks#
- All the communication with the equipment is handled by the driver in the backend.
- The existing content of the file is erased and the new data will be saved.
