Lot Traveler Printable Documents Specifics#

PrintableDocuments that are to be used as Lot Traveler pages must have the Type set to Lot Traveler.

When a PrintableDocument is of Type Lot Traveler the system will have some specific behaviors, namely:

  • The AppliesTo property will be ReadOnly and automatically set to Material
  • The PrinterType property will be ReadOnly and automatically set to General
  • A set of pre-defined Context Items will be added automatically (see below)

Predefined Context Items#

The system will automatically add three pre-defined Context Items to Lot Traveler PrintableDocuments, namely:

  • Step - which will be filled with the Step object for which the Lot Traveler document is being printed
  • Flow - which will be filled with the Flow object corresponding to the current Flow of the Material for which the Lot Traveler document is being printed
  • Flow Path - which will be filled with the FlowPath string of the Step for which the Lot Traveler is being printed
  • LogicalFlowPath - which will be filled with the LogicalFlowPath string of the Step for which the Lot Traveler is being printed

These Context Items cannot be removed by the user, and only the values of the Description and StoreHistory properties can be modified.

Screenshot showing a diagram illustrating the step in the LogicalFlowPath.

Also, the user cannot add additional Context Items of Type Input, but any number of Context Items of Type Variable can be added.
