Integration#

var serviceProvider = (IServiceProvider)Input["ServiceProvider"];
IEntityFactory entityFactory = serviceProvider.GetService<IEntityFactory>();
IMaterialOrchestration materialOrchestration = serviceProvider.GetService<IMaterialOrchestration>();

//Obtain the Integration Entry created by the external system in CM MES.
IIntegrationEntry integrationEntry = Input["IntegrationEntry"] as Cmf.Foundation.BusinessObjects.IntegrationEntry;

//The message in the Integration Entry in always stored as an byte array.
//Convert the byte array to a dictionary and then to the desired json object.
string jsonString = Encoding.UTF8.GetString(integrationEntry.IntegrationMessage.Message);
Dictionary<string,object> data = JsonConvert.DeserializeObject<Dictionary<string,object>>(jsonString);
JObject materialInfo = JObject.FromObject(data["Cookie"]);

//Obtain all the fields present in the message.
string facilityName = materialInfo["Facility"].ToString();
IFacility facility = entityFactory.Create<IFacility>();
facility.Load(facilityName);

string flowName = materialInfo["Flow"].ToString();
IFlow flow = entityFactory.Create<IFlow>();
flow.Load(flowName);

string stepName = materialInfo["Step"].ToString();
IStep step = entityFactory.Create<IStep>();
step.Load(stepName);

string productName = materialInfo["Product"]["Name"].ToString();
string productVersion = materialInfo["Product"]["Version"].ToString();
string productRevision = materialInfo["Product"]["Revision"].ToString();
IProduct product = entityFactory.Create<IProduct>();
product.Name = productName;
product.Version = int.Parse(productVersion);
product.Revision = productRevision;
product.Load();

int cookiePrimaryQuantity = (int)materialInfo["Quantity"];

//Instantiate the material entity with the necessary properties.
IMaterial material = entityFactory.Create<IMaterial>();
material.Facility = facility;
material.Flow = flow;
material.Step = step;
material.Form = "Cookie"; //Always cookie, since this is a Cookie Integration. This can be configured. example: using a configuration entry.
material.Product = product;
material.PrimaryQuantity = cookiePrimaryQuantity;
material.Type = "Cookie"; //Always cookie, since this is a Cookie Integration. This can be configured. example: using a configuration entry.

//Call the material orchestration to create the instantiated material.
CreateMaterialInput input = new CreateMaterialInput();
input.Material = material;
materialOrchestration.CreateMaterial(input);
