Store Data#

The Store Data task allows you to store values in a shared context that can be retrieved later using the Retrieve Data task. It supports both persistent and temporary storage modes.

Inputs#

Name Data Type Description
<custom list> <custom> Value to store
Activate any Store all values

Outputs#

Name Data Type Description
Success Boolean True value emitted when the values are stored
Error Error Error that occurred during the processing of this task

Settings#

On the General Tab, you have the usual settings and the following setting:

Name Data Type Values Default Description
Working Mode enum StoreOnValueChange
StoreOnActivate		 StoreOnValueChange Expected behavior to store the data

Screenshot showing a table with columns labeled Name, Data Type, Values, Default, and Description.

On the Inputs tab, each item that belongs to the custom list has the following settings:

Name Data Type Values Default Description
Name String Name that will identify the stored value
Identifier any Unique identifier that will represent the value
Type Long
Decimal
DateTime
Boolean
String
Integer		 Type of data expected to be stored
Collection Type None
Array
Map		 None Collection Type of data to store (not yet used)
Storage enum Persistent
Temporary		 Retention type of the store

Screenshot showing storage settings with options for persistent and temporary retention types.

Behavior#

If Working Mode is set to StoreOnActivate then the data will be stored only when the Activate input is triggered and all inputs will be stored at the same time.

If Working Mode is set to StoreOnValueChange then each and every time the input value is changed, it will be immediately stored.

If the Storage is set to Temporary, then the data will only be stored during the lifetime of the Automation Controller process. The moment it is closed or restarted, the data will be lost.

The Identifier is supposed to be unique throughout the entire controller. Duplicate identifiers will remain with the latest values, no matter who wrote it.

Note

The data is persisted within a store unique for the Automation Controller Instance. This means that changing versions will not affect the data. Terminating an Automation Controller Instance will render the data inaccessible.

Remarks#

Writing <Null> into a Data Item will remove it from the store.

Make sure the identifiers are unique within the controller.

The persisted data will be stored in the persistence entry defined in the Automation Manager configuration file.
